Western Foundries offers rough and finish machining, drilling and milling for any size
casting.
Our capabilities include:
Partial list of machines, larger component machining also available:
Vertical Machining Centers:
Daewoo DMV 650
Travels X-50”, Y-25”, Z-22”
Daewoo DMV 500
Travels X-30”, Y-20”, Z-22.44”
CNC Lathes:
Daewoo Puma 400 Long Bed/Live Tooling
12 station turret, travel Z-84.8”
Swing 30.3”, turning capacity 22.0”
Daewoo Puma 350 (Qty 2)
10 station turret, travel Z-43.5”
Swing 27.56”, turning capacity 21.7”
Daewoo Puma 200
12 station turret, travel Z-17.32”
Swing 20.08”, turning capacity 13.78”
Daewoo Puma 10S
12 station turret, travel Z-31.5”
Swing 22.4”, turning capacity 15.0”
Cincinnati Horizontal Machining Center
24”x24” table with pallet changer
Travels X-40.4”, Y-31.5”, Z-31.5”
Summit Horizontal Boring Mill
Travels X-56”, Y-65”, Z-51”
Maximum Table Load: 11,000 pounds
Okuma V100R Vertical Turret Lathe
12 Station Turret
Travels X-22.2”, X-35.0”
Swing 49.2”, turning capacity 39.97”
Other:
Qty - 8 Manual Engine Lathes
Qty - 2 Fosdick Radial Drill 4’ Arm
Qty - 3 Bridgeport Mills
Welding:
GTAW, GMAW, SMAW
Welders ASME Sect IX certified
WPS per ASTM A488-1995
PQR for standard materials plus
A20, CD4MCu, CF3, CF3M
casting.
Our capabilities include:
- 20,000 square foot machining facility
- Full range of heavy machining/welding equipment
- 600 square foot painting facility, sandblasting
- 2-Plane balancing capability
- Hydrostatic testing for pressure parts
- Complete range inspection equipment
- Heat treat services
- Cryogenic treatment services
Partial list of machines, larger component machining also available:
Vertical Machining Centers:
Daewoo DMV 650
Travels X-50”, Y-25”, Z-22”
Daewoo DMV 500
Travels X-30”, Y-20”, Z-22.44”
CNC Lathes:
Daewoo Puma 400 Long Bed/Live Tooling
12 station turret, travel Z-84.8”
Swing 30.3”, turning capacity 22.0”
Daewoo Puma 350 (Qty 2)
10 station turret, travel Z-43.5”
Swing 27.56”, turning capacity 21.7”
Daewoo Puma 200
12 station turret, travel Z-17.32”
Swing 20.08”, turning capacity 13.78”
Daewoo Puma 10S
12 station turret, travel Z-31.5”
Swing 22.4”, turning capacity 15.0”
Cincinnati Horizontal Machining Center
24”x24” table with pallet changer
Travels X-40.4”, Y-31.5”, Z-31.5”
Summit Horizontal Boring Mill
Travels X-56”, Y-65”, Z-51”
Maximum Table Load: 11,000 pounds
Okuma V100R Vertical Turret Lathe
12 Station Turret
Travels X-22.2”, X-35.0”
Swing 49.2”, turning capacity 39.97”
Other:
Qty - 8 Manual Engine Lathes
Qty - 2 Fosdick Radial Drill 4’ Arm
Qty - 3 Bridgeport Mills
Welding:
GTAW, GMAW, SMAW
Welders ASME Sect IX certified
WPS per ASTM A488-1995
PQR for standard materials plus
A20, CD4MCu, CF3, CF3M
